High quality Bluetooth RFID Scanner can buit-in 1D/ 2D barcode reader for warehouse managementHigh quality Bluetooth RFID Scanner can buit-in 1D/ 2D barcode reader for warehouse managementHigh quality Bluetooth RFID Scanner can buit-in 1D/ 2D barcode reader for warehouse management

High quality Bluetooth RFID Scanner can buit-in 1D/ 2D barcode reader for warehouse management

Product Introduction:

Product ID: RK1302

Packaging & Delivery

Packaging Details barcode scanner

Delivery Time 7 work days after payment

Compatible OS: Android, Windows, Linux

Projects: Warehouse management,Logistiscs.Medical Management,Express Industry


Product details

High quality Bluetooth RFID Scanner can buit-in 1D/ 2D barcode reader for warehouse management


Product Parameter

Light source  red

5600K LEDs (illumination illumination) LED 625 ± 10nm (aim aimer)

Image Sensor

640 x 480 CMOS

Processor

ARM32-bit

Resolution

≥4mil/0.1mm(PCS90%,CODE 39)

Read depth of field

10mm~650mm

Reading mode

induction reading /manual reading

Prompt mode

Buzzer/ LED

Read angle

Test ConditionsCODE39,10mil/0.25mm,PCS90%


Rotate Roll: ± 360 °, tilt Pitch: ± 55 °, skew Skew: ± 50 °

Print contrast

≥25%

Ambientintensity

0-10000LUX light

Reading code system

1D:UPC-A,UPC-E,EAN-8,EAN-13, Code 128, GS1-128, Code 39,Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Codabar(NW-7),MSI, etc.

2D: QR Code,PDF417,Data Matrix,etc.

Mechanical / electrification performance

Body weight

<110g(No wire)

Dimension

150mm L * 70mm W * 95mm H

Interface

USB(USB-KBW/USB-COM)、RS232

Wire length

1.5m

Material

ABS

Color

Black

Operating Voltage

DC 5V

Current

150mA(Working),50mA(Standby)



Working environment

Working Temp

-20℃ to 50℃

Storage Temp

-40℃ to 70℃

Work humidity

5% to 95%(No condensation)

Protection class

IP42

Drop Test

1.5m,100 times

High and low temperature test

30 minutes for high Temp., 30 minutes for low Temp.,

High temperature

60℃

Low

-20℃

Transport vibration test

10H@125RPM

Accessories list

Data lines

USB data cable for connecting the host terminal


RS232 data cable for connecting the host terminal with a power adapter DC connector

Power adapter (optional)

Output:DC 5V, 1A;Input: AC 100~240V, 50~60Hz

Test conditions: room temperature 25 , ambient illumination 200LUX, PCS = 0.9
